Filling and capping machine

YCGZ is suitable for liquid filling and capping in pharmaceutical, healthcare, food industry, etc. The machine uses single rail (dual rail for YCGZ-2) to feed bottle, the bottle is transferred by conveying belt, and dialing wheel positions the bottle.

Filling and capping machine-637
Filling and capping machine-638
Filling and capping machine-639
Inquire Now

Functions

lShut down without bottle

lBottle arrive and machine resume

lNo cap machine stop

lScrew capping has flip unit, do not hurt cap

lProduct quantity count

lAlarm display



Features

lCompact machine

l4 (10 for YCGZ-2) piston pump measuring filling for accurate filling volume.

lServo system+ stainless steel pump filling

lThe pump and other contact parts with drug liquid are SS316L

lThe working table is covered by stainless steel.

lCompliant with GMP requirement




  • Technical Details
  • URS
  • Download

YCGZ-1

YCGZ-2

YCGZ-3

Applied range

30-500 mL

30-500 mL

30-500 mL

Capacity

40-60 b/min

80-100 b/min

40-60 b/min; 80-100 b/min

Filling method

servo system+stainless steel pump

Filling accuracy

± 1%

Compressed air consumption

0.5-0.6 MPa 5m3/h

Filling head

4 heads

10 heads

4 heads

Capping head

1 head

2 heads

1 head

Total power

2.0 kW

Power supply

220V 50Hz

Noise

≤65 dB(A)

Total weight

Around 800 kg

Around 1000 kg

Around 800 kg

Overall size

2440*1350*1700 mm

3300*1100*1700 mm

2440*1350*1700 mm


Download

Brochure

User’s Manual

    Filling and capping machine
